ASTM A790 UNS S39277 Stainless Steel Tube For Chemical And Process Industry
Specifications
ASTM A790 covers seamless and straight-seam welded ferritic/austenitic stainless steel pipe intended for general-purpose applications.
ASTM A790 UNS S39277 stainless steel tube it is a highly alloyed grade designed to offer exceptional performance in the most aggressive environments, particularly where high chloride content, acidity, and erosion are concerns.
| American Standard | Standard Name |
| A 790 / SA 790 | Seamless and Welded Ferritic/Austenitic Stainless Steel Pipe |
ASTM A790 UNS S39277 Stainless Steel Tube Chemical Composition
(Sources American Standard A790 / A790M TABLE 2 Chemical Requirements)
| UNS Designation A | C | Mn | P | S | Si | Ni | Cr | Mo | N | Cu | Others |
| S39277 | 0.025 | 0.8 | 0.025 | 0.002 | 0.8 | 6.5–8.0 | 24.0–26.0 | 3.00–4.00 | 0.23–0.33 | 1.2-2.00 | W 0.80-1.2 |
ASTM A790 UNS S39277 Stainless Steel Tube Mechanical Properties
(Sources American Standard A790 / A790M TABLE 3 Tensile and Hardness Requirements)
| UNS Designation | Tensile strength, | Yield strength, | Elongation | Hardness, max | |
| min, | min | in 2 in. or 50 | |||
| ksi[MPa] | ksi[MPa] | mm, min,% | HNW | HRC | |
| S39277 | 120 [825] | 90 [620] | 25 | 290 | 30 |
ASTM A790 UNS S39277 Stainless Steel Tube Application
ASTM A790 UNS S39277 Stainless Steel Tube Packing & Loading
